- Details
1000 Mbps (1 Gbps) | Single Mode Fiber | LC | 10 km (6.2 mi) | Lifetime Warranty
The 10056-ST is an Extreme Networks 10056 compatible downstream fiber SFP transceiver which pairs with StarTech.com's 10057-ST. They are designed, programmed and tested to work with 1000BASE-BX-D compatible Extreme Networks switches and routers. The SFP transceiver module supports a maximum distance of up to 10 km (6.2 mi) and delivers dependable 1 GbE connectivity over fiber cabling.
Technical Specifications:
Wavelength: 1490nmTx/1310nmRx
Maximum Data Transfer Rate: 1Gbps
Type: Single Mode Fiber
Connection Type: LC Connector
Maximum Transfer Distance: 10 km (6.2 mi)
Power Consumption:
DDM: Yes
This SFP fiber module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.
StarTech.com SFPs
All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP Cables, providing the convenience and reliability you need to ensure dependable network performance.
The StarTech.com Advantage
| Performance | |
| SFP transceiver type: | Fiber optic |
| Maximum data transfer rate: | 1250 Mbit/s |
| Interface type: | SFP |
| Single-mode fiber (SMF) supported: | Yes |
| Multi-mode fiber (MMF) supported: | No |
| Fiber optic connector: | LC |
| SFP transceiver standard: | BX |
| Maximum transfer distance: | 10000 m |
| Tx wavelength (max): | 1490 nm |
| Rx wavelength (max): | 1310 nm |
| Networking standards: | IEEE 802.3z |
| Fiber ethernet cabling technology: | 1000BASE |
| Duplex system: | Full |
| Digital Diagnostics Monitoring (DDM): | Yes |
| Features | |
| Product colour: | Silver |
| Hot-swap: | Yes |
| Mean time between failures (MTBF): | 286217327 h |
| Brand compatibility: | Extreme Networks |
| Compatible products: | 10056 |
| Power | |
| Power consumption (typical): | 1.3 W |
| Certificates | |
| Certification: | CE, FCC, UR, REACH |
| Weight & dimensions | |
| Width: | 56.6 mm |
| Depth: | 13.7 mm |
| Height: | 12.5 mm |
| Weight: | 20 g |
| Packaging content | |
| Quantity per pack: | 1 pc(s) |
| Packaging data | |
| Package width: | 90 mm |
| Package depth: | 115 mm |
| Package height: | 31 mm |
| Package weight: | 50 g |
| Logistics data | |
| Master (outer) case width: | 90 mm |
| Master (outer) case length: | 115 mm |
| Harmonized System (HS) code: | 85369010 |
| Master (outer) case height: | 31 mm |
| Products per master (outer) case: | 1 pc(s) |
