Products description
| Performance | |
| Type: | IP security camera |
| Placement supported: | Indoor & outdoor |
| Connectivity technology: | Wired |
| PTZ control: |  |
| Wide Dynamic Range (WDR): |  |
| Day/night mode: | |
| Remote viewing: | |
| Infrared (IR) cut-off filter: | |
| Number of languages: | 15 |
| Languages support: | Simplified Chinese, Czech, German, Dutch, English, Spanish, French, Italian, Japanese, Korean, Polish, Portuguese, Russian, Swedish, Turkish |
| Dynamic range: | 120 dB |
| Design | |
| Mounting type: | Ceiling |
| Product colour: | White |
| Form factor: | Dome |
| Housing material: | Plastic |
| Protection features: | Dust resistant, Splash proof |
| International Protection (IP) code: | IP66 |
| IK code: | IK10 |
| Camera | |
| Camera pan control: | |
| Camera tilt control: | |
| Minimum illumination: | 0.03 lx |
| Angle of rotation: | 355° |
| Lens viewing angle, horizontal: | 113.7° |
| Lens viewing angle, vertical: | 61.5° |
| Lens viewing angle, diagonal: | 134.4° |
| Tilt angle range: | 0 - 67° |
| Pan range: | 0 - 350° |
| White balance: | ATW, AWC, Indoor, Manual, Outdoor |
| Camera shutter type: | Electronic |
| Image sensor | |
| Sensor type: | CMOS |
| Number of sensors: | 1 |
| Optical sensor size: | 25.4 / 2.8 mm (1 / 2.8") |
| Progressive scan: | |
| Number of effective pixels (H x V): | 1984 x 1105 pixels |
| Lens system | |
| Number of lenses: | 1 |
| Zoom capability: | |
| Fixed focus: | |
| Maximum aperture number: | 2 |
| Identify distance: | 0.5 m |
| Fixed focal length: | 2.8 mm |
| Closest focusing distance: | 0.5 m |
| Night vision | |
| Night vision: | |
| Night vision distance: | 30 m |
| LED type: | IR |
| Video | |
| Maximum resolution: | 1920 x 1080 pixels |
| Total megapixels: | 2 MP |
| Video formats supported: | H.264, M-JPEG |
| Video compression formats: | H.264, M-JPEG |
| Supported graphics resolutions: | 320 x 240, 640 x 360, 640 x 480 (VGA), 720 x 576, 800 x 448, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080) |
| Frame rate: | 30 fps |
| Video streaming: | |
| Noise reduction: | |
| Flip & mirror: | |
| Privacy masking: | |
| Bit rate control: | Constant Bit Rate (CBR), Variable Bit Rate (VBR) |
| Back Light Compensation (BLC): | |
| Network | |
| Ethernet LAN: | |
| Ethernet interface type: | Fast Ethernet |
| Networking standards: | IEEE 802.3af |
| Supported network protocols: | IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour |
| Number of users: | 6 user(s) |
| Quality of Service (QoS) support: | |
| Streaming method: | Multicast, Unicast |
| Storage | |
| Card reader integrated: | |
| Compatible memory cards: | MicroSD (TransFlash), MicroSDHC |
| Maximum memory card size: | 32 GB |
| Flash memory: | 256 MB |
| Internal memory: | 512 MB |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports: | 1 |
| Security | |
| Video motion detection: | |
| Active tampering alarm: | |
| IP address filtering: | |
| Security algorithms: | 802.1x RADIUS, EAP-LEAP, EAP-TLS, HTTPS |
| HTTPS encryption: | |
| Alert notification type: | |
| Anti-flicker: | |
| Mirror: | |
| Management features | |
| Web browser: | |
| Power | |
| Power source type: | PoE |
| Power consumption (typical): | 5 W |
| Power consumption (Power over Ethernet (PoE)): | 6.4 W |
| Operational conditions | |
| Operating temperature (T-T): | -30 - 55 °C |
| Storage temperature (T-T): | -30 - 55 °C |
| Operating relative humidity (H-H): | 0 - 90% |
| Storage relative humidity (H-H): | 0 - 90% |
| System requirements | |
| Windows operating systems supported: | Windows 10, Windows 7, Windows 8.1 |
| Mac operating systems supported: | Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave |
| Weight & dimensions | |
| Width: | 120.3 mm |
| Height: | 91.7 mm |
| Diameter: | 12 cm |
| Weight: | 410 g |
