Digitus 24 Port Gigabit Network Switch

24 Port Gigabit Network Switch, 2 uplink ports, flow control, 8K MAC address table, VLAN- Supports IEEE802.3, IEEE802.3u, IEEE802.3x, IEEE802.3az- Flow control for full duplex operation and back pressure for half duplex operation- Supports VLAN mode- LED lights for monitoring the operating status and for fault analysis- Line speed forwarding, smart identification- 48 Gbps switching capacity- MAC address table: 8K- Supports jumbo frame up to 9216K bytes- Line speed forwarding, smart identification- 48 Gbps switching capacityThe DN-80113-1 has 24 10/100/1000 Mbps RJ45 ports, with port 23 and port 24 as the uplink ports. It uses store-and-forward technology in combination with the dynamic memory allocation for each port. The integrated VLAN function can improve the network environment and reduces network maintenance costs. The DN-80113-1 is easy to manage and maintain.

Management features
Switch type:	Unmanaged
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity:	24
Basic switching RJ-45 Ethernet ports type:	Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity:	24
Power connector:	AC-in jack
Network
Networking standards:	IEEE 802.3, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
10G support:
Full duplex:
Half duplex:
Flow control support:
Ethernet LAN data rates:	10,100,1000 Mbit/s
VLAN support:
Data transmission
MAC address table:	8000 entries
Switching capacity:	48 Gbit/s
Forwarding rate:	35.7 Mpps
Jumbo frames support:
Jumbo frames:	9216
Packet buffer memory:	4.1 MB
Design
Stackable:
Product colour:	Black
Housing material:	Metal
LED indicators:
Vandal-proof:
Suitable for outdoor use:
Country of origin:	China
Power
Power source:	AC
Power supply included:
Power over Ethernet (PoE)
Power over Ethernet (PoE):
Weight & dimensions
Width:	280 mm
Depth:	179 mm
Height:	44 mm
Weight:	1.54 kg
Packaging data
Manual:
Package width:	370 mm
Package depth:	230 mm
Package height:	80 mm
Package volume:	6808 cm³
Package weight:	1.84 kg
Other features
Ethernet interface type:	Gigabit Ethernet
Logistics data
UK Trade Tariff code:	85176200
