Products description
| Features | |
| Number of inputs: | 9 inputs |
| Number of outputs: | 20 outputs |
| Output frequency range (satellite): | 950 - 2150 MHz |
| Output frequency range (terrestrial): | 87 - 790 MHz |
| Channel bandwidth: | 68 MHz |
| Through loss (satellite): | -5 dB |
| Through loss (terrestrial): | 9 dB |
| Decoupling (outputs): | 25 dB |
| Digital Satellite Equipment Control (DiSEqC): | 1.0 |
| Power | |
| Input voltage: | 230 V |
| Input frequency: | 50/60 Hz |
| Operational conditions | |
| Operating temperature (T-T): | -25 - 45 °C |
| Operating relative humidity (H-H): | 10 - 70% |
| Weight & dimensions | |
| Weight: | 600 g |
| Package width: | 156 mm |
| Package depth: | 265 mm |
| Package height: | 57 mm |
| Package weight: | 1.05 kg |
