Products description
Omada Cloud Essentials A Free and Easy Cloud-Based Network Management
Omada Cloud Essentials is a free, easy-to-use version of the Omada Cloud-based Controller. It provides cloud-based centralized management and monitoring for the Omada networking system, covering access points, switches, and gateways, ideal for surveillance networks and small businesses.
| Management features | |
| Switch type: | Managed |
| Switch layer: | L2 |
| Quality of Service (QoS) support: | Yes |
| Web-based management: | Yes |
| Cloud-managed: | Yes |
| Unified static configuration: | Yes |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity: | 26 |
| Basic switching RJ-45 Ethernet ports type: | Gigabit Ethernet (10/100/1000) |
| Gigabit Ethernet (copper) ports quantity: | 26 |
| SFP module slots quantity: | 2 |
| Network | |
| Networking standards: | IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| 10G support: | No |
| Copper ethernet cabling technology: | 10BASE-T, 100BASE-X, 1000BASE-T, 1000BASE-X |
| Port mirroring: | Yes |
| Flow control support: | Yes |
| Link aggregation: | Yes |
| Broadcast storm control: | Yes |
| Auto MDI/MDI-X: | Yes |
| Ethernet LAN data rates: | 10,100,1000 Mbit/s |
| Fast leave: | Yes |
| VLAN support: | Yes |
| Virtual LAN features: | MTU VLAN, Port-based VLAN, Tagged VLAN |
| Number of VLANs: | 32 |
| Data transmission | |
| MAC address table: | 8000 entries |
| Switching capacity: | 56 Gbit/s |
| Forwarding rate: | 41.66 Mpps |
| Store-and-forward: | Yes |
| Jumbo frames support: | Yes |
| Jumbo frames: | 15000 |
| Packet buffer memory: | 4 MB |
| Security | |
| DHCP features: | DHCP client |
| IGMP snooping: | Yes |
| Queue scheduling algorithms: | Weighted Round Robin (WRR) |
| Multicast features | |
| Multicast support: | Yes |
| Design | |
| Rack mounting: | Yes |
| Product colour: | Black |
| Housing material: | Metal |
| LED indicators: | Yes |
| Number of fans: | 2 fan(s) |
| Performance | |
| Flash memory: | 64 MB |
| Noise level: | 46.2 dB |
| Firmware upgradeable: | Yes |
| Fanless: | No |
| Mean time between failures (MTBF): | 224143 h |
| Power | |
| Power source: | AC |
| Power supply included: | Yes |
| AC input voltage: | 100 - 240 V |
| AC input frequency: | 50/60 Hz |
| Power consumption (max): | 454.8 W |
| Surge protection: | Yes |
| Surge protection voltage: | 6 kV |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE): | Yes |
| Power over Ethernet (PoE) type supported: | PoE+ |
| Power over Ethernet plus (PoE+) ports quantity: | 24 |
| Power over Ethernet (PoE) power per port: | 30 W |
| Total Power over Ethernet (PoE) budget: | 384 W |
| Operational conditions | |
| Operating temperature (T-T): | -5 - 45 °C |
| Storage temperature (T-T): | -40 - 70 °C |
| Operating relative humidity (H-H): | 10 - 90% |
| Storage relative humidity (H-H): | 5 - 90% |
| Heat dissipation: | 1546.15 BTU/h |
| Weight & dimensions | |
| Width: | 440 mm |
| Depth: | 330 mm |
| Height: | 44 mm |
| Packaging content | |
| Cables included: | AC |
| Quick start guide: | Yes |
| Manual: | Yes |
| Rack mount kit: | Yes |
| Certificates | |
| Compliance certificates: | CE, Federal Communications Commission (FCC), RoHS |
| Certification: | FCC, CE, RoHS |
