QNAP HS-453DX NAS Tower Ethernet LAN Gold, White J4105

The 2018 Computex d&i Design Award-winning HS-453DX features a stylish minimalist appearance while providing maximum multimedia performance. Powered by an Intel® Celeron® J4115 quad-core processor with HDMI 2.0 (4K @60Hz) output, the HS-453DX allows you to directly enjoy high-quality videos on a 4K HDTV, and fits seamlessly within an existing home theater setup. With a fanless design, the HS-453DX remains quiet under operation, allowing you to fully enjoy a multimedia experience without any distracting noise. True 4K, greater multimedia enjoyment than everFeaturing advanced Intel® UHD Graphics 600, the HS-453DX supports dual-channel 4K H.264 hardware decoding and real-time transcoding, allowing you to convert videos to universal file formats that can be smoothly played on multiple devices*. The QNAP RM-IR004 remote control can be configured using QButton to customize the actions of individual buttons, providing a more convenient NAS experience.The connectivity needed for great media entertainmentThe HS-453DX features a modern set-top design and appearance to fit alongside your existing home theater devices. The HS-453DX provides a wealth of connectivity to ensure all your different needs, including USB 3.2 Gen 1 Type-C & Type-A port and USB 2.0 ports, HDMI 2.0/1.4 dual output, 3.5mm line-out and more. The HS-453DX also provides an accessible hard drive layout, making it easier than ever to add and remove 3.5-inch hard drives.Uncompromising performance and speedPowered by an Intel® Celeron® J4115 quad-core 1.8 GHz processor (burst up to 2.5 GHz), with 4GB/8GB DDR4 memory (up to 8GB dual-channel memory), and supporting SATA 6Gb/s drives, the HS-453DX delivers high-performance read/write speeds and maintains high speeds even with AES-NI encryption enabled. The HS-453DX also provides dual M.2 2280 SATA SSD slots to configure SSD caching to further improve the performance. 10GbE connectivity is also provided with a built-in 10GBASE-T five-speed port (supports 10G/5G/2.5G/1G/100M) that allows you to use existing Cat 5e, 6 or 6a cables for instantly enjoying higher network speeds.Transfer massive media files with high-speed 10GbE connectivityWith 10GbE connectivity, transferring and managing media files is much more efficient. Recently-encoded video and music files can be quickly transferred to the HS-453DX via 10GbE connection. (If you are looking to upgrade your network environment to 10GbE, QNAP also provides a variety of accessible switches, adapters and other solutions).Smoother media viewing with SSD caching and SSD Over-provisioningThe HS-453DX features a Hybrid HDD + SSD structure. As SSD prices continue to fall, you can flexibly allocate applications to SSDs, set up a SSD cache, or use Qtier technology to automatically move frequently-accessed files to SSD for the highest access speeds. With support for software-defined SSD RAID extra over-provisioning (OP), the HS-453DX enables you to allocate additional OP space (1% to 60%) to optimize SSD random write speeds and to extend SSD lifespan. Your file backup and multimedia entertainment will be smoother than ever!Complete control over system status and data securityQNAP Notification Center integrates all notification settings of the NAS and its applications into a single app, providing central management and greater convenience. The Security Counselor also scans the HS-453DX for potential weaknesses and provides recommendations to improve security.Safeguard your data with backup and snapshot protectionQNAP provides a reliable, flexible backup & disaster recovery solution. With snapshots you can fully record the system status and data and quickly recover to this status if data is lost.Easy Photo Management with QuMagie-Enabled AI Automated Photo CategorizationQuMagie brings you a brand-new photo management experience. By integrating an AI deep-learning algorithm, QuMagie enables facial recognition, object identification, and geography tagging of photos on your NAS. Similar photos are grouped together in the AI Albums (i.e., People, Things, and Places). Other useful features include a built-in timeline scroll, customizable folder covers, and a powerful search tool, providing you with the ultimate photo management and sharing solution.Access your file from anywhereThe HS-453DX centrally stores data and files, and supports SMB/CIFS, AFP and NFS protocols for file sharing across Windows®, Mac®, and Linux®/UNIX® devices. Coupled with Qsync (a utility that turns a QNAP NAS into a safe, high-capacity data center for file synchronization), any file uploaded to the HS-453DX will be made available for all linked devices, such as computers, laptops and mobile devices.

Storage
Storage drives installed:
Number of storage drives supported:	2
Installed storage drive type:
Supported storage drive types:	HDD & SSD
RAID support:
Supported storage drive interfaces:	M.2, Serial ATA III
Storage drive sizes supported:	2.5,3.5"
Number of M.2 (M & B) slots:	2
RAID levels:	0, 1, 5, 6, 10, JBOD
Online RAID migration:
Online RAID expansion:
RAID rebuild:
Hot-swap drive bays:
Supported file systems:	FAT32, HFS+, NTFS, exFAT, ext3, ext4
Bad block scan:
Processor
Processor family:	Intel® Celeron®
Processor manufacturer:	Intel
Processor model:	J4105
Processor frequency:	1.5 GHz
Processor boost frequency:	2.5 GHz
Processor cores:	4
Processor threads:	4
Processor cache:	4 MB
CPU configuration (max):	1
ECC supported by processor:
PCI Express configurations:	1x2, 1x2+2x1, 1x4, 2x1, 4x1
PCI Express slots version:	2.0
Processor codename:	Gemini Lake
Processor lithography:	14 nm
Processor operating modes:	64-bit
Processor package size:	25 x 24 mm
Processor socket:	BGA 1090
Tjunction:	105 °C
Thermal Design Power (TDP):	10 W
On-board graphics card model:	Intel® UHD Graphics 600
Maximum internal memory supported by processor:	8 GB
Conflict-Free processor:
Memory
Internal memory:	8 GB
Internal memory type:	DDR4
Maximum RAM supported:	8 GB
Memory slots:	2
Flash memory:	4096 MB
Network
Ethernet LAN:
Ethernet LAN data rates:	10,100,1000,2500,5000,10000 Mbit/s
Wi-Fi:
DHCP client:
DHCP server:
Jumbo frames support:
iSCSI support:
Wake-on-LAN ready:
Supported network protocols:	TCP/IP, HTTP/HTTPS
Link aggregation:
Fault tolerance:
Load balancing system:
Dynamic DNS (DDNS):
Ports & interfaces
Ethernet LAN (RJ-45) ports:	2
USB port:
USB 2.0 ports quantity:	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity:	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity:	1
HDMI ports quantity:	2
HDMI version:	1.4b/2.0
3.5 mm (1/8-inch) out:
Microphone in:
Graphics
On-board graphics card base frequency:	250 MHz
On-board graphics card burst frequency:	750 MHz
On-board graphics card dynamic frequency (max):	750 MHz
On-board graphics card DirectX version:	12.0
On-board graphics card ID:	0x3185
Maximum on-board graphics card memory:	8 GB
Number of displays supported (on-board graphics):	3
Design
Chassis type:	Tower
Product colour:	Gold, White
LED indicators:	Status
Built-in speaker(s):
Number of built-in speakers:	1
Performance
Type:	NAS
Device class:	Home & Home Office
Backup function:
Backup features:	Cloud, iSCSI LUN
Noise level:	13 dB
Noise level (idle):	6.2 dB
Snapshot:
Management protocols:	SNMP v2/v3
Web-based management:
Security algorithms:	256-bit AES, FIPS 140-2, HTTPS, SSH
Reset button:
On/off switch:
Built-in iTunes server:
Built-in FTP server:
Browser supported:	Apple Safari 7+, Google Chrome, Microsoft Internet Explorer 10+, Mozilla Firefox
System log:
Hot spare:
S.M.A.R.T. support:
Share folder:	CIFS/SMB
Remotely operated:
Software
Operating system installed:	QNAP Turbo System
Operating system version:	5.0.0
Windows operating systems supported:	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64
Linux operating systems supported:
Mac operating systems supported:	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supported:	Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Power
Power supply location:	Built-in
Power supply unit (PSU) capacity:	90 W
Power consumption (typical):	22.38 W
Power consumption (sleep):	13.55 W
AC input voltage:	100 - 240 V
Weight & dimensions
Width:	404 mm
Depth:	220 mm
Height:	42.8 mm
Weight:	2.4 kg
Packaging content
External power adapter:
Cables included:	AC, LAN (RJ-45)
Quick installation guide:
Number of screws:	16
Remote control included:
Processor special features
Embedded options available:
Enhanced Intel SpeedStep Technology:
Execute Disable Bit:
Idle States:
Intel 64:
Intel Enhanced Halt State:
Intel Identity Protection Technology version:	1.00
Intel Secure Key Technology version:	1.00
Intel Smart Response Technology version:	0.00
Intel Virtualization Technology (VT-x):
Intel Virtualization Technology for Directed I/O (VT-d):
Intel VT-x with Extended Page Tables (EPT):
Intel® AES New Instructions (Intel® AES-NI):
Intel® Anti-Theft Technology (Intel® AT):
Intel® Hyper Threading Technology (Intel® HT Technology):
Intel® Identity Protection Technology (Intel® IPT):
Intel® OS Guard:
Intel® Quick Sync Video Technology:
Intel® Secure Key:
Intel® Smart Response Technology:
Intel® Turbo Boost Technology:
Maximum number of PCI Express lanes:	6
Number of execution units:	12
Thermal Monitoring Technologies:
Memory channels supported by processor:	Dual
Memory types supported by processor:	DDR4-SDRAM, LPDDR4-SDRAM
Operational conditions
Operating temperature (T-T):	0 - 35 °C
Operating relative humidity (H-H):	5 - 95%
Logistics data
Harmonized System (HS) code:	84714100
Other features
Digital Living Network Alliance (DLNA) certified:
Processor ARK ID:	128989
