Products description
Impeccable imaging for advanced insights
Make faster, informed decisions with a camera that can differentiate normal activity vs. suspicious behavior and tell you when you need to step in.
Coverage anytime, anywhere
Rain, sleet or shine, our camera is ready for the challenge with IP66/67, Type 4K and IK10 ratings.
Real-time threat detection
Quickly identify situations requiring your attention with enhanced object detection and classification.
Elevate your camera
Reduce maintenance costs using cloud-based machine learning to eliminate processes of manually checking on your cameras.
Seamless integrations
This modular camera is built on an open system for straightforward installation and configuration.
| Performance | |
| Type: | IP security camera |
| Placement supported: | Outdoor |
| Connectivity technology: | Wired |
| Wide Dynamic Range (WDR): | Yes |
| Day/night mode: | Yes |
| Infrared (IR) cut-off filter: | Yes |
| Alarm input/output: | Yes |
| Dynamic range: | 126 dB |
| Certification: | UL/CSA/EN/IEC 62368-1, IEC 62471, FCC Part 15 Subpart B (Class B), IC ICES-003 (Class B), EN 55032 (Class B), EN 61000-6-3, EN 61000-3-2, EN 61000-3-3, EN 55035, EN 61000-6-1, EN 50130-4, EN 50121-4 |
| Design | |
| Mounting type: | Wall |
| Product colour: | Black, White |
| Form factor: | Bullet |
| Housing material: | Aluminium |
| Protection features: | Weatherproof |
| International Protection (IP) code: | IP66, IP67 |
| IK code: | IK10 |
| Weatherproof: | Yes |
| Camera | |
| Minimum illumination: | 0.005 lx |
| Angle of rotation: | 350° |
| Lens viewing angle, horizontal: | 95° |
| Lens viewing angle, vertical: | 69° |
| Tilt angle range: | -90 - 90° |
| Pan range: | -175 - 175° |
| White balance: | Auto, Manual |
| Camera shutter type: | Electronic |
| Camera shutter speed: | 1/7.5 - 1/30000 s |
| Number of Privacy masking areas: | 64 |
| Image sensor | |
| Sensor type: | CMOS |
| Number of sensors: | 1 |
| Optical sensor size: | 25.4 / 2.8 mm (1 / 2.8") |
| Lens system | |
| Number of lenses: | 1 |
| Zoom capability: | Yes |
| Focal length range: | 3.4 - 10.5 mm |
| Auto focus: | Yes |
| Focus: | Motorized |
| Maximum aperture number: | 1.6 |
| Night vision | |
| Night vision: | Yes |
| Night vision distance: | 50 m |
| LED type: | IR |
| Infra-red wavelength: | 850 nm |
| Video | |
| Maximum resolution: | 2592 x 1944 pixels |
| Total megapixels: | 5 MP |
| Video formats supported: | H.264, H.265, M-JPEG |
| Supported graphics resolutions: | 384 x 288, 512 x 288, 512 x 384, 640 x 360, 640 x 480 (VGA), 768 x 432, 800 x 600 (SVGA), 1280 x 720 (HD 720), 1280 x 960, 1440 x 1080, 1600 x 1200 (UXGA), 1920 x 1080 (HD 1080), 2560 x 1440, 2592 x 1944 |
| Frame rate: | 30 fps |
| Video intelligence analytic: | Yes |
| Video streaming: | Yes |
| Noise reduction: | Yes |
| Noise reduction technology: | 3D noise reduction |
| Back Light Compensation (BLC): | Yes |
| Audio | |
| Audio formats supported: | G.711, PCM |
| Sample rate: | 8 kHz |
| Signal-to-Noise Ratio (SNR): | 50 dB |
| Network | |
| Ethernet LAN: | Yes |
| Ethernet interface type: | Fast Ethernet |
| Networking standards: | IEEE 802.3af |
| Supported network protocols: | IPv6, IPv4, HTTP, HTTPS, SOAP, DNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMPv3, ICMP, DHCP, Zeroconf, HSTS, RTP/UDP, RTP/UDP multicast, RTP/RTSP/TCP, RTP/RTSP/HTTP/TCP, RTP/RTSP/HTTPS/TCP, HTTP, SRTP, SNMP v2c, SNMP v3 |
| Streaming method: | Multicast |
| Storage | |
| Card reader integrated: | Yes |
| Compatible memory cards: | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Maximum memory card size: | 1.5 TB |
| Flash memory: | 512 MB |
| RAM capacity: | 1000 MB |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports: | 1 |
| USB port: | Yes |
| Security | |
| Password protection: | Yes |
| Video motion detection: | Yes |
| HTTPS encryption: | Yes |
| Privacy protection: | Yes |
| Intelligent Video Surveillance (IVS) system features: | Line crossing detection, Missing object, Moving object, Region entrance detection, Region exiting detection |
| Digest authentication: | Yes |
| Power | |
| Power source type: | Battery, PoE |
| Power consumption (Power over Ethernet (PoE)): | 13 W |
| Battery | |
| Battery technology: | Lithium |
| Operational conditions | |
| Operating temperature (T-T): | -40 - 60 °C |
| Storage temperature (T-T): | -10 - 70 °C |
| Operating relative humidity (H-H): | 0 - 95% |
| Storage relative humidity (H-H): | 0 - 95% |
| Weight & dimensions | |
| Width: | 126 mm |
| Depth: | 294 mm |
| Height: | 104 mm |
| Weight: | 1.31 kg |
| Sustainability | |
| Compliance certificates: | BIS, CE, KC, Norma Oficial Mexicana (NOM), RCM, RoHS, UKCA, UL, cUL |
| Packaging content | |
| Number of cameras: | 1 |
