- Details
Experience immersive gaming with the MAG 345CQRF E20 gaming monitor. It features a 3440x1440 (UWQHD) panel, a 200Hz refresh rate, and a rapid 0.5ms (GtG, Min) response time. The monitor is HDR Ready, enhancing eye-catching details through adjustments in contrast and shadows. Designed for competitive FPS, first-person RPG/MMORPG, and flight/racing simulator genres, the MSI MAG 345CQRF E20 gaming monitor takes casual gaming to a new level, challenging players to see beyond the game.
MSI's mainstream MAG series epitomizes stability and durability and is built to withstand the most intense gaming sessions. The entire lineup features robust construction with metallic-like hardness and excellent heat dissipation, ensuring stability for all critical gaming components.
| Display | |
| Display diagonal: | 86.4 cm (34") |
| Display resolution: | 3440 x 1440 pixels |
| Native aspect ratio: | 21:9 |
| Touchscreen: | No |
| HD type: | UltraWide Dual Quad HD |
| Panel type: | Rapid VA |
| Response time: | 0.5 ms |
| Screen shape: | Curved |
| Contrast ratio (typical): | 3500:1 |
| Maximum refresh rate: | 200 Hz |
| Display number of colours: | 1.07 billion colours |
| Display brightness (typical): | 300 cd/m² |
| Response time measurement type: | GTG (Gray to Gray) |
| Anti-glare screen: | Yes |
| Screen curvature rating: | 1000R |
| Supported graphics resolutions: | 3440 x 1440 |
| Supported video modes: | 1440p |
| Contrast ratio (dynamic): | 100000000:1 |
| Viewing angle, horizontal: | 178° |
| Viewing angle, vertical: | 178° |
| Pixel pitch: | 0.23175 x 0.23175 mm |
| Horizontal scan range: | 70.51 - 285.31 kHz |
| Vertical scan range: | 48 - 200 Hz |
| Viewable size, horizontal: | 79.7 cm |
| Viewable size, vertical: | 33.4 cm |
| Display diagonal (metric): | 86.36 cm |
| Colour gamut standard: | DCI-P3 |
| Colour gamut: | 90% |
| sRGB coverage (typical): | 110% |
| NTSC coverage (typical): | 88% |
| DCI-P3 coverage: | 90% |
| Performance | |
| NVIDIA G-SYNC: | No |
| AMD FreeSync: | No |
| Multimedia | |
| Built-in speaker(s): | No |
| Built-in camera: | No |
| Design | |
| Market positioning: | Gaming |
| Product colour: | Black |
| Frameless design: | Yes |
| Feet colour: | Black |
| Ports & interfaces | |
| Built-in USB hub: | No |
| HDMI: | Yes |
| Headphone out: | Yes |
| HDMI ports quantity: | 2 |
| HDMI version: | 2.0b |
| DisplayPorts quantity: | 1 |
| DisplayPort version: | 1.4a |
| Headphone outputs: | 1 |
| Ergonomics | |
| VESA mounting: | Yes |
| Cable lock slot: | Yes |
| Height adjustment: | Yes |
| Panel mounting interface: | 100 x 100 mm |
| Cable lock slot type: | Kensington |
| Adjustable height (max): | 10 cm |
| Pivot: | Yes |
| Pivot angle: | -1.5 - 1.5° |
| Swivelling: | Yes |
| Swivel angle range: | -30 - 30° |
| Tilt adjustment: | Yes |
| Tilt angle range: | -5 - 20° |
| Power | |
| Energy efficiency class (SDR): | F |
| Energy efficiency class (HDR): | G |
| Energy consumption (SDR) per 1000 hours: | 31 kWh |
| Energy consumption (HDR) per 1000 hours: | 57 kWh |
| Power consumption (standby): | 0.5 W |
| Power consumption (off): | 0.3 W |
| AC input voltage: | 100 - 240 V |
| AC input frequency: | 50/60 Hz |
| Input current: | 3.42 A |
| AC adapter output voltage: | 19 V |
| Power supply type: | External |
| Energy efficiency scale: | A to G |
| Weight & dimensions | |
| Width (with stand): | 797.5 mm |
| Depth (with stand): | 332.3 mm |
| Height (with stand): | 418.9 mm |
| Weight (with stand): | 7.75 kg |
| Width (without stand): | 797.5 mm |
| Depth (without stand): | 158.2 mm |
| Height (without stand): | 363 mm |
| Packaging data | |
| Package width: | 985 mm |
| Package depth: | 228 mm |
| Package height: | 510 mm |
| Package weight: | 11.3 kg |
| Package type: | Box |
| Packaging content | |
| Stand included: | Yes |
| Cables included: | AC, Audio (3.5mm), DisplayPort, Power |
| Quick start guide: | Yes |
