LevelOne POI-3010 PoE adapter Fast Ethernet, Gigabit Ethernet 52 V

The LevelOne POI-3010 is a single port, high power PoE PSE solution for remote PoE PD devices. Generating up to 30W , the POI-3010 supplies remote power for new applications such as wireless access points, pan-tilt-zoom (PTZ) IP cameras and videophones. It complies with IEEE 802.3at PoE standard and is backward compatible to IEEE802.3af. It can work with 10/100Base-T networking devices and emerging 1000Base-T devices such as Wi-MAX and wireless IEEE 802.11ac access points. For all the function featured in POI-3010, people can get the benefit of flexible network installation at lower cost and less downtime. It also provides a high-bandwidth pipe to the network.

Network
Ethernet interface type:	Fast Ethernet, Gigabit Ethernet
Ethernet LAN data rates:	10,100,1000 Mbit/s
Power over Ethernet (PoE):
Networking standards:	IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Features
Product colour:	Black
Wall mountable:
Plug and Play:
Surge protection:
Maximum operating distance:	100 m
LED indicators:	PoE, Power
Pin assignment & polarity:	1/2 (+), 3/6 (-)
Certification:	FCC Part 15, CE
Ports & interfaces
Ethernet LAN (RJ-45) ports:	2
Power
Power over Ethernet (PoE) voltage:	52 V
AC adapter input voltage:	100 - 240 V
AC adapter frequency:	50/60 Hz
Input current:	0.8 A
Output current:	0.6 A
Power consumption (max):	30 W
Power over Ethernet (PoE) power per port:	30 W
Operational conditions
Operating temperature (T-T):	0 - 45 °C
Operating relative humidity (H-H):	5 - 95%
Storage temperature (T-T):	0 - 70 °C
Storage relative humidity (H-H):	5 - 95%
Weight & dimensions
Width:	143 mm
Depth:	51 mm
Height:	38 mm
Weight:	350 g
Packaging data
Package width:	210 mm
Package depth:	125 mm
Package height:	55 mm
Package weight:	400 g
Package type:	Box
Packaging content
Number of products included:	1 pc(s)
Power cord included:
Quick installation guide:
Technical details
Sustainability certificates:	RoHS
Logistics data
Harmonized System (HS) code:	85044095
