LevelOne 1m Antenna Cable, CFD-400, N Male Plug to N Male Plug, Indoor/Outdoor

LevelOne provides a higher performance CFD 400 cable with excellent flexibility. All cables designed for low loss general-purpose indoor/outdoor applications.WeatherabilityCDF 400 cables designed for outdoor exposure incorporate the best materials for UV resistance.

Features
Cable length:	1 m
Connector 1:
Connector 2:
Cable type:	CFD400
Connector 1 gender:	Male
Connector 2 gender:	Male
Connector 1 form factor:	Straight
Connector 2 form factor:	Straight
Product colour:	Black
Impedance:	50
Frequency band:	0 - 6 GHz
Jacket outer diameter:	1.03 cm
Jacket material:	Polyethylene (PE), Polyvinyl chloride (PVC)
Conductor size:	2.74 mm
Insulation thickness:	2.2 mm
Load capacitance:	23.9 pF
Voltage Standing Wave Ratio (VSWR):	1.2 - 1.5
Country of origin:	Taiwan
Operational conditions
Operating temperature (T-T):	-30 - 60 °C
Operating relative humidity (H-H):	0 - 95%
Weight & dimensions
Width:	270 mm
Depth:	270 mm
Height:	35 mm
Packaging data
Quantity per pack:	1 pc(s)
Weight:	197.5 g
Package width:	300 mm
Package depth:	300 mm
Package height:	35 mm
Package weight:	215 g
Logistics data
Harmonized System (HS) code:	85442000
Master (outer) case width:	485 mm
Master (outer) case length:	410 mm
Master (outer) case height:	290 mm
Master (outer) case gross weight:	12 kg
Products per master (outer) case:	50 pc(s)
