Products description
| Power | |
| Total power: | 450 W |
| AC input voltage: | 230 V |
| AC input frequency: | 50 Hz |
| Input current: | 5 A |
| Power Factor Correction (PFC) type: | Active |
| Combined power (+3.3V): | 115 W |
| Combined power (+12V): | 340 W |
| Combined power (+5V): | 115 W |
| Combined power (+5Vsb): | 18.5 W |
| Max output current (+3.3V): | 20 A |
| Max output current (+12V1): | 16 A |
| Max output current (+12V2): | 18 A |
| Max output current (+5V): | 22 A |
| Max output current (-12V): | 0.5 A |
| Max output current (+5Vsb): | 2.5 A |
| Efficiency: | 88% |
| Power protection features: | Over current, Over power, Over voltage, Short circuit, Under voltage |
| Ports & interfaces | |
| Motherboard power connector: | 20+4 pin ATX |
| Peripheral (Molex) power connectors (4-pin): | 4 |
| Motherboard power cable length: | 45 cm |
| Number of SATA power connectors: | 4 |
| Number of PATA power connectors: | 4 |
| SATA power cable length: | 750 mm |
| Peripheral (Molex) power cable length: | 600 mm |
| PCI Express power connectors (6+2 pin): | 1 |
| PCI Express power cable length: | 45 cm |
| CPU power connector (4+4 pin): |  |
| CPU power cable length: | 45 cm |
| ATX power connector (20+4 pin): | |
| PCI Express connector: | |
| Performance | |
| Purpose: | PC |
| Power supply unit (PSU) form factor: | ATX |
| 80 PLUS certification: | 80 PLUS Bronze |
| ATX version: | 2.3 |
| Certification: | CE / TÜV |
| Design | |
| Product colour: | Black |
| Cooling type: | Active |
| Fan diameter: | 12 cm |
| Number of fans: | 1 fan(s) |
| Fan location: | Top |
| On/off switch: | |
| Weight & dimensions | |
| Width: | 150 mm |
| Depth: | 140 mm |
| Height: | 86 mm |
| Weight: | 1.7 kg |
| Packaging data | |
| Package type: | Box |
| Technical details | |
| Sustainability certificates: | RoHS |
