- Details
Intel® Virtualization Technology for Directed I/O (VT-d)
Intel® Virtualization Technology for Directed I/O (VT-d) continues from the existing support for IA-32 (VT-x) and Itanium® processor (VT-i) virtualization adding new support for I/O-device virtualization. Intel VT-d can help end users improve security and reliability of the systems and also improve performance of I/O devices in virtualized environments.
Intel® Virtualization Technology (VT-x)
Intel® Virtualization Technology (VT-x) allows one hardware platform to function as multiple virtual platforms. It offers improved manageability by limiting downtime and maintaining productivity by isolating computing activities into separate partitions.
Intel® AES New Instructions
Intel® AES New Instructions (Intel® AES-NI) are a set of instructions that enable fast and secure data encryption and decryption. AES-NI are valuable for a wide range of cryptographic applications, for example: applications that perform bulk encryption/decryption, authentication, random number generation, and authenticated encryption.
Max Turbo Frequency
Max Turbo Frequency is the maximum single-core frequency at which the processor is capable of operating using Intel® Turbo Boost Technology and, if present, Intel® Turbo Boost Max Technology 3.0 and Intel® Thermal Velocity Boost. Frequency is typically measured in gigahertz (GHz), or billion cycles per second.
Intel® Rapid Storage Technology
Intel® Rapid Storage Technology provides protection, performance, and expandability for desktop and mobile platforms. Whether using one or multiple hard drives, users can take advantage of enhanced performance and lower power consumption. When using more than one drive the user can have additional protection against data loss in the event of hard drive failure. Successor to Intel® Matrix Storage Technology.
Integrated Graphics
Integrated graphics allow for incredible visual quality, faster graphic performance and flexible display options without the need for a separate graphics card.
Intel® Optane Memory Supported
Intel® Optane memory is a revolutionary new class of non-volatile memory that sits in between system memory and storage to accelerate system performance and responsiveness. When combined with the Intel® Rapid Storage Technology Driver, it seamlessly manages multiple tiers of storage while presenting one virtual drive to the OS, ensuring that data frequently used resides on the fastest tier of storage. Intel® Optane memory requires specific hardware and software configuration.
RAID Configuration
RAID (Redundant Array of Independent Disks) is a storage technology that combines multiple disk drive components into a single logical unit, and distributes data across the array defined by RAID levels, indicative of the level of redundancy and performance required.
Intel® Platform Trust Technology (Intel® PTT)
Intel® Platform Trust Technology (Intel® PTT) is a platform functionality for credential storage and key management used by Windows 8* and Windows® 10. Intel® PTT supports BitLocker* for hard drive encryption and supports all Microsoft requirements for firmware Trusted Platform Module (fTPM) 2.0.
| Processor | |
| Built-in processor: | Yes |
| Processor manufacturer: | Intel |
| Processor family: | Intel® Core i9 |
| Processor generation: | 13th gen Intel® Core i9 |
| Processor model: | i9-13900K |
| Processor cores: | 24 |
| Processor threads: | 32 |
| Processor boost frequency: | 5.8 GHz |
| Processor cache: | 36 MB |
| L2 cache: | 32 MB |
| Thermal Design Power (TDP): | 125 W |
| CPU configuration (max): | 1 |
| Memory | |
| Memory slots type: | SO-DIMM |
| Number of memory slots: | 2 |
| Number of DIMM slots: | 2 |
| Maximum internal memory: | 64 GB |
| Supported memory types: | DDR-SDRAM |
| Memory channels: | Dual-channel |
| ECC: | No |
| Storage | |
| Supported storage drive types: | HDD & SSD |
| Storage drive sizes supported: | M.2,2.5 |
| SSD form factor: | M.2 |
| Storage drive interface: | PCI Express, Serial ATA III |
| Number of storage drives supported: | 5 |
| RAID levels: | 0, 1 |
| Graphics | |
| On-board graphics card: | No |
| Graphics card family: | Intel |
| On-board graphics card model: | Intel UHD Graphics 770 |
| Maximum resolution: | 7680 x 4320 pixels |
| Number of displays supported: | 3 |
| Audio | |
| Built-in speaker(s): | No |
| Network | |
| Ethernet LAN: | Yes |
| Wi-Fi: | Yes |
| Top Wi-Fi standard: | Wi-Fi 6E (802.11ax) |
| Wi-Fi standards: | Wi-Fi 6E (802.11ax) |
| WLAN controller model: | Killer Wi-Fi 6E AX1690 |
| Bluetooth: | Yes |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: | 2 |
| HDMI ports quantity: | 1 |
| Ethernet LAN (RJ-45) ports: | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: | 6 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: | 1 |
| HDMI version: | 2.1 |
| Microphone in: | Yes |
| Headphone outputs: | 1 |
| Combo headphone/mic port: | Yes |
| Number of SATA III connectors: | 4 |
| M.2 card slot (wireless): | Killer Wi-Fi 6E AX1690i |
| USB ports quantity: | 11 |
| M.2 card slot (storage): | 2 via PCH + 1 via CPU (NVMe) |
| Thunderbolt 4 ports quantity: | 2 |
| Expansion slots | |
| PCI Express slots version: | 5, 4.0 |
| Design | |
| Chassis type: | Desktop |
| Product colour: | Black |
| Cooling type: | Active |
| Product type: | PC barebone |
| On/off switch: | Yes |
| LED indicators: | Yes |
| Cable lock slot: | Yes |
| Cable lock slot type: | Kensington |
| ARK ID: | 229782 |
| Certification: | IEC/EN/UL 60950-1 IEC/EN/UL 62368-1 FCC Part 15B/15C/15E CISPR/EN 55032/55024 ICES-003 VCCI 32 BSMI CNS 13438 KN 32/35 AS/NZS CISPR 32 EN 300 328 EN 301 893 EN 300 440 EN 301 489-1/3/17 EN 62311 AS/NZS 4268 AS/NZS 2772.2 ARPANSA |
| Performance | |
| Motherboard chipset: | Intel Z690 |
| Number of processors supported: | 1 |
| BIOS type: | EEPROM |
| Audio output channels: | 7.1 channels |
| Windows operating systems supported: | Windows 11 x64 |
| Linux operating systems supported: | Yes |
| Compatible operating systems: | Windows 11 (64-bit) |
| Operating system installed: | No |
| Commodity Classification Automated Tracking System (CCATS): | G157815L2 |
| Export Control Classification Number (ECCN): | 5A992C |
| Processor special features | |
| Embedded options available: | No |
| Intel Rapid Storage Technology: | Yes |
| Intel® AES New Instructions (Intel® AES-NI): | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d): | Yes |
| Intel VT-x with Extended Page Tables (EPT): | Yes |
| Intel 64: | Yes |
| Idle States: | Yes |
| Enhanced Intel SpeedStep Technology: | Yes |
| Intel Flex Memory Access: | Yes |
| Intel Trusted Execution Technology: | Yes |
| Execute Disable Bit: | Yes |
| Intel Stable Image Platform Program (SIPP): | Yes |
| Intel® Optane Memory Ready: | Yes |
| Intel® Platform Trust Technology (Intel® PTT): | Yes |
| Intel Virtualization Technology (VT-x): | Yes |
| Technical details | |
| Sustainability certificates: | ENERGY STAR, RoHS |
| Introduction year: | 2022 |
| Warranty period: | 3 year(s) |
| Logistics data | |
| Harmonized System (HS) code: | 8471500150 |
| Power | |
| Power supply type: | Internal power supply unit |
| Power supply: | 750 W |
| Number of power supply units: | 1 |
| Operational conditions | |
| Operating temperature (T-T): | 0 - 35 °C |
| Storage temperature (T-T): | -20 - 40 °C |
| Weight & dimensions | |
| Width: | 337 mm |
| Depth: | 318 mm |
| Height: | 129 mm |
| Packaging content | |
| Power cord included: | Yes |
| Other features | |
| Additional headers: | FRONT_PANEL |
| Number of SATA connectors: | 4 |
| HDD size: | 2.5" |
| Status: | Launched |
| Product family: | Intel NUC |
| Product series: | Intel NUC kit |
| Product codename: | Raptor Canyon |
| Launch date: | Q4'22 |
