The Gryphon 4600 scanners, designed with sustainability, usability, and advanced technology at their core, are the first in their category to incorporate an eco-design approach, featuring low power consumption, recycled materials, and eco-friendly packaging to help reduce carbon footprint. Performance-wise, it delivers fast and accurate reading of all common 1D and 2D codes, including GS1 Digital Link, Digital Watermarking, and dense high-resolution codes. Dual-sensor optics (HP models) enable reliable scanning from near to far distances,while advanced AI algorithms and a powerful dual-core processor boost speed and motion tolerance for first-pass reads of moving codes. User-friendly and intuitive, it offers a bright green central cross LED aimer for precise targeting, complemented by Datalogic s recognized Green Spot, 3GL (3 Green Lights), and vibration feedback. Dual-color LED illumination (warm white and red) adapts instantly to any scanning requirement. Wireless connectivity includes Bluetooth 5.2 (classic and BLE) and Datalogic s STAR Cordless System, paired with inductive wireless charging that eliminates contact wear and maintenance, ensuring continuous 24/7 operation.
| Scanning | |
| Type: | Handheld bar code reader |
| Scanner type: | 2D |
| Sensor type: | Laser |
| Linear (1D) barcodes supported: | GS1 DataBar, GS1 DataBar Expanded, PDF417 |
| 2D (matrix & stacked) barcodes supported: | Aztec Code, Data Matrix, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked Omnidirectional, MaxiCode, Micro QR Code, MicroPDF417, QR Code, DotCode |
| Light levels (direct sunlight): | 0 - 110000 lx |
| Tilt reading angle: | 0 - 360° |
| Pitch reading angle: | -65 - 65° |
| Yaw reading angle: | -65 - 65° |
| Ports & interfaces | |
| Connectivity technology: | Wired |
| Standard interfaces: | USB |
| Performance | |
| Product colour: | Black |
| International Protection (IP) code: | IP52 |
| Power | |
| Power source type: | Battery |
| Battery voltage: | 12 V |
| Number of reads per charge: | 80000 |
| Charging time: | 3.5 h |
| Weight & dimensions | |
| Weight: | 144 g |
| Width: | 65 mm |
| Depth: | 79 mm |
| Height: | 180 mm |
| Packaging data | |
| Cables included: | USB |
| Operational conditions | |
| Operating temperature (T-T): | 0 - 50 °C |
| Storage temperature (T-T): | -40 - 70 °C |
| Operating relative humidity (H-H): | 5 - 95% |
| Battery | |
| Battery technology: | Lithium-Ion (Li-Ion) |
| Battery capacity: | 3250 mAh |
| Technical details | |
| Compliance certificates: | RoHS |
