- Details
Powerful Switching for your Business
The DGS-1100 Series is a range of powerful switches that offer a lot of bang for your buck. They are great for busy SMBs who expect a lot of their network, including support for surveillance and VoIP. They are packed with traffic management & optimization features that keep your network congestion free. Meanwhile, management tools are flexible and intuitive, making your life easier.
Easy to Use & Easy to Install
D-Link Network Assistant Utility (DNA) can quickly discover and do initial setup for D-Link Networking devices such as the DGS-1100 Series, which greatly improves efficiency for solution deployment.
VLANs: Stronger Security & Better Traffic Management
Relatively easy to set up, VLANs can be a big boon for your network. They can isolate sensitive areas of your network, keeping them safe from those with malicious intent, or keeping bandwidth open for latency-sensitive traffic such as VoIP.
Green Technology
D-Link Green technology enables the DGS-1100 Smart Managed Switches to save power without sacrificing performance. Most of the models in the series utilize a fanless design, for silent and energy-efficient operation. All are IEEE 802.3az-compliant and feature Link Status detection and Time-Based PoE.
PD Alive Actively Mitigates Downtime
Round-the-clock surveillance footage is vital. If you have Cameras attached to your network,
you may have thought technical difficulties were a given. However, the PD-Alive feature actively mitigates device downtime. If a device is not working as expected, the Switch can automatically reset them and get them back online. No need to turn them on and off again in the middle
of the night.
| Management features | |
| Switch type: | Managed |
| Switch layer: | L2 |
| Quality of Service (QoS) support: | Yes |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity: | 16 |
| Basic switching RJ-45 Ethernet ports type: | Gigabit Ethernet (10/100/1000) |
| Combo SFP ports quantity: | 2 |
| Network | |
| Networking standards: | IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x |
| 10G support: | No |
| Copper ethernet cabling technology: | 1000BASE-T |
| Full duplex: | Yes |
| Half duplex: | Yes |
| Flow control support: | Yes |
| Link aggregation: | Yes |
| Auto MDI/MDI-X: | Yes |
| Spanning tree protocol: | Yes |
| Ethernet LAN data rates: | 10,100,1000 Mbit/s |
| Auto-negotiation: | Yes |
| VLAN support: | Yes |
| Number of VLANs: | 4094 |
| Data transmission | |
| Switching capacity: | 36 Gbit/s |
| Forwarding rate: | 26.78 Mpps |
| Jumbo frames support: | Yes |
| Jumbo frames: | 9216 |
| Security | |
| IGMP snooping: | Yes |
| Design | |
| Rack mounting: | Yes |
| Form factor: | 1U |
| Product colour: | Black |
| Number of fans: | 1 fan(s) |
| Electromagnetic compatibility: | FCC Class A, CE Class A, VCCI Class A, C-Tick, BSMI |
| Performance | |
| Noise level: | 45.8 dB |
| Mean time between failures (MTBF): | 343695 h |
| Power | |
| Power source: | DC/PoE |
| Power supply included: | Yes |
| AC input voltage: | 100 - 240 V |
| AC input frequency: | 50 - 60 Hz |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE): | Yes |
| Power over Ethernet (PoE) ports quantity: | 16 |
| Total Power over Ethernet (PoE) budget: | 130 W |
| Operational conditions | |
| Operating temperature (T-T): | -5 - 50 °C |
| Storage temperature (T-T): | -40 - 70 °C |
| Operating relative humidity (H-H): | 0 - 95% |
| Storage relative humidity (H-H): | 0 - 95% |
| Heat dissipation: | 125.2 BTU/h |
| Weight & dimensions | |
| Width: | 280 mm |
| Depth: | 230 mm |
| Height: | 44 mm |
| Weight: | 2.1 kg |
| Certificates | |
| Compliance certificates: | RoHS |
| Certification: | cUL, UL, LVD, CB, BSMI |
