- Details
CyberPower OLS1000ERT2UA is a high-performance UPS featuring online double-conversion topology, which provides seamless Pure Sine Wave power for mission-critical devices such as NAS and servers, DVRs/surveillance systems, transportation and infrastructure, and emergency systems. It s typically integrated in the back office, server room, and data center environment.
The UPS features color LCD panel for users to monitor power system and configure settings easily. This model can be used with compatible Extended Battery Modules (EBM) to prolong system runtime during power interruption. The variable speed fans provide automatic thermal management based on power load to reduce noise and provide greater comfort for users. The product also supports power management software to perform real-time monitoring and remote management.
| Features | |
| UPS topology: | Double-conversion (Online) |
| Output power capacity: | 1 kVA |
| Output power: | 900 W |
| Waveform: | Pure sine |
| Input operation voltage (min): | 160 V |
| Input operation voltage (max): | 300 V |
| Input frequency: | 50/60 Hz |
| Output operation voltage (min): | 208 V |
| Output operation voltage (max): | 240 V |
| Output frequency: | 50/60 Hz |
| Output frequency regulation: | 0.5 Hz |
| Output voltage regulation: | 1% |
| Maximum current: | 4.5 A |
| Surge energy rating: | 363 J |
| Response time: | 0 ms |
| Heat dissipation: | 380 BTU/h |
| Number of input phases: | 1 |
| Number of output phases: | 1 |
| Efficiency (ECO mode): | 95% |
| Input power factor: | 0.99 |
| Output power factor: | 0.9 |
| ECO mode: | Yes |
| Emergency Power Off (EPO): | Yes |
| Output voltage Total Harmonic Distortion (THD): | 5% |
| EMI/RFI noise filtering: | Yes |
| Surge protection: | Yes |
| Power protection features: | Overload |
| Audible alarm(s): | Yes |
| Audible alarm modes: | Battery replacement, Low battery alarm, Overload alarm, Fault, Alarm when on battery |
| Ports & interfaces | |
| AC outlet types: | C13 coupler |
| Power plug: | Type F |
| AC outlets quantity: | 8 AC outlet(s) |
| USB port: | Yes |
| USB port type: | USB Type-B |
| Serial interface: | Yes |
| Serial interface type: | RS-232 |
| Serial ports quantity: | 1 |
| RS-232 ports: | 1 |
| Modem (RJ-11) ports: | 1 |
| Ethernet LAN (RJ-45) ports: | 1 |
| Emergency Power Off (EPO) connector: | Yes |
| Battery | |
| Battery technology: | Sealed Lead Acid (VRLA) |
| Battery voltage: | 24 V |
| Number of batteries supported: | 3 |
| Number of batteries included: | 2 pc(s) |
| Typical backup time at full load: | 4.6 min |
| Typical backup time at half load: | 13.9 min |
| Battery recharge time: | 4 h |
| Charging current: | 1.5 A |
| Hot-swap battery: | Yes |
| Replacement battery cartridge: | RBP0156 |
| Design | |
| Form factor: | Rackmount/Tower |
| Product colour: | Black |
| Housing material: | Metal |
| Rack capacity: | 2U |
| Cable length: | 1.5 m |
| Cooling type: | Active |
| Built-in fan: | Yes |
| Control type: | Buttons |
| Display type: | LCD |
| Operational conditions | |
| Operating temperature (T-T): | 0 - 40 °C |
| Storage temperature (T-T): | -20 - 50 °C |
| Operating relative humidity (H-H): | 5 - 95% |
| Storage relative humidity (H-H): | -20 - 50% |
| Operating altitude: | 0 - 1500 m |
| Certificates | |
| Compliance certificates: | CE, EAC, RoHS |
| Packaging content | |
| Batteries included: | Yes |
| Rack mount kit: | Yes |
| Cables included: | Input power cable, USB cable |
| Manual: | Yes |
| Weight & dimensions | |
| Width: | 438 mm |
| Depth: | 430 mm |
| Height: | 88 mm |
| Weight: | 13.5 kg |
| Packaging data | |
| Package width: | 540 mm |
| Package depth: | 550 mm |
| Package height: | 230 mm |
| Package weight: | 17.7 kg |
| Logistics data | |
| Country of origin: | China |
