The 10-in-1 USB 3.2 Gen 2 MST Docking Station is a powerful and versatile connectivity solution designed to expand your workstation with maximum performance and flexibility. Supporting both HDMI and DisplayPort video outputs, it delivers exceptional image quality with resolutions up to 4K 60Hz and 8K 30Hz. Windows users can benefit from dual extended display support via MST, enabling efficient multitasking across multiple screens.
Featuring three high-speed USB-C ports with data transfer rates up to 10Gbps and two USB-A ports for everyday peripherals, this docking station provides reliable and seamless connectivity for all your essential devices. The integrated Gigabit Ethernet port ensures stable wired network performance up to 1000 Mbps, ideal for office environments and bandwidth-intensive tasks.
With USB-C Power Delivery pass-through up to 100W, you can power and charge your laptop while maintaining full functionality of connected devices. The built-in 3.5 mm combo audio jack allows convenient connection of headsets for clear communication during meetings and calls. Housed in a durable aluminum casing for efficient heat dissipation, this docking station supports simple Plug and Play installation and offers wide compatibility with Windows, macOS, and ChromeOS. It is a complete, professional solution for streamlined and productive workspaces.
| Ports & interfaces | |
| Connectivity technology: | Wired |
| Host interface: | USB 3.2 Gen 2 (3.1 Gen 2) Type-C |
| USB 2.0 ports quantity: | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: | 0 |
| HDMI ports quantity: | 1 |
| Headphone outputs: | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: | 4 |
| USB Power Delivery (USB PD): | Yes |
| USB Power Delivery revision: | 3.0 |
| USB Power Delivery up to: | 100 W |
| HDMI version: | 2.0 |
| DisplayPorts quantity: | 1 |
| DisplayPort version: | 1.4 |
| Combo headphone/mic port: | Yes |
| Headphone connectivity: | 3.5 mm |
| Network | |
| Ethernet LAN: | Yes |
| Ethernet LAN (RJ-45) ports: | 1 |
| Ethernet LAN data rates: | 10,100,1000 Mbit/s |
| Wake-on-LAN ready: | Yes |
| Networking standards: | IEEE 802.3ab |
| Performance | |
| Product colour: | Grey |
| Card reader integrated: | No |
| Data transfer rate: | 10 Gbit/s |
| HD type: | 8K Ultra HD |
| Maximum digital resolution: | 7680 x 4320 pixels |
| Plug and Play: | Yes |
| Housing material: | Aluminium |
| Country of origin: | China |
| Power | |
| USB cable length: | 0.2 m |
| Software | |
| Windows operating systems supported: | Yes |
| Mac operating systems supported: | Yes |
| Other operating systems supported: | ChromeOS |
| Operational conditions | |
| Operating temperature (T-T): | 0 - 45 °C |
| Weight & dimensions | |
| Width: | 64.6 mm |
| Depth: | 120 mm |
| Height: | 17 mm |
| Weight: | 157 g |
| Packaging data | |
| Package width: | 95 mm |
| Package depth: | 200 mm |
| Package height: | 20 mm |
| Package weight: | 200 g |
| Packaging content | |
| Quick start guide: | Yes |
| Technical details | |
| Compliance certificates: | CE, RoHS |
| Logistics data | |
| Products per master (outer) case: | 40 pc(s) |
| Master (outer) case width: | 220 mm |
| Master (outer) case length: | 400 mm |
| Master (outer) case height: | 255 mm |
| Master (outer) case gross weight: | 8.9 kg |
| Customs product code (TARIC): | 8471800000 |
| Pallet gross width: | 120 cm |
| Pallet gross length: | 80 cm |
| Pallet gross height: | 168.2 cm |
| Other features | |
| Master (outer) cases per pallet: | 60 pc(s) |
