Brocade 8x 10GBase-SR SFP+ network transceiver module Fiber optic 10000 Mbit/s SFP+

Brocade optical transceiver modules connect Brocade switches, directors, backbones, HBAs, and CNAs to a broad spectrum of data center resources, providing Fibre Channel and Ethernet connectivity, and satisfying a wide range of speed and distance requirements.

Performance
SFP transceiver type:	Fiber optic
Maximum data transfer rate:	10000 Mbit/s
Interface type:	SFP+
Multi-mode fiber (MMF) supported:
Fiber optic connector:	LC
Fiber cable diameters supported (core/cladding):	50/125,62.5/125 µm
SFP transceiver standard:	SR
Maximum transfer distance:	300 m
Cabling technology:	10GBASE-SR
Auto MDI/MDI-X:
Features
Hot-Plug support:
Certification:	MSA
Operational conditions
Operating temperature (T-T):	0 - 70 °C
Storage temperature (T-T):	-40 - 85 °C
Operating relative humidity (H-H):	10 - 80%
Storage relative humidity (H-H):	10 - 85%
Weight & dimensions
Width:	13.4 mm
Depth:	56.5 mm
Height:	8.5 mm
Logistics data
Harmonized System (HS) code:	85369010
