Chieftec GPU-550FC | Chieftec PowerPlay power supply unit 550 W 20+4 pin ATX PS/2 Black, Red

Your settings

Languages

Welcome back!

You do not have any products in your shopping cart yet.

Products description

Power
Total power:	550 W
AC input voltage:	100 - 240 V
AC input frequency:	47 - 63 Hz
Input current:	8 A
Power factor:	0.9
Power Factor Correction (PFC) type:	Active
Combined power (+3.3V):	110 W
Combined power (+12V):	550.8 W
Combined power (+5V):	110 W
Combined power (-12V):	3.6 W
Combined power (+5Vsb):	15 W
Max output current (+3.3V):	20 A
Max output current (+12V):	45.9 A
Max output current (+5V):	20 A
Max output current (-12V):	0.3 A
Max output current (+5Vsb):	3 A
Power protection features:	Over current, Over power, Over voltage, Overheating, Short circuit
Ports & interfaces
Motherboard power connector:	20+4 pin ATX
Peripheral (Molex) power connectors (4-pin):	3
Motherboard power cable length:	60 cm
Number of SATA power connectors:	6
SATA power cable length:	150,800 mm
Peripheral (Molex) power cable length:	150,700 mm
EPS power connector (8-pin):	Yes
PCI Express power connectors (6+2 pin):	2
PCI Express power cable length:	60 cm
ATX power connector (20+4 pin):	Yes
Floppy drive power connector:	1
Floppy disk drive connector:	Yes
PCI Express connector:	Yes
Cabling type:	Fully-Modular
Performance
Purpose:	PC
Power supply unit (PSU) form factor:	PS/2
80 PLUS certification:	80 PLUS Gold
ATX version:	2.3
Design
Product colour:	Black, Red
Cooling type:	Active
Fan diameter:	14 cm
Number of fans:	1 fan(s)
Fan location:	Top
On/off switch:	Yes
Weight & dimensions
Width:	150 mm
Depth:	160 mm
Height:	86 mm
Weight:	2.24 kg
Packaging data
Package weight:	2.65 kg
Package type:	Box
Logistics data
Harmonized System (HS) code:	84733020

Product Safety Information
Responsible Person in the EU:
Arena Electronic GmbH Koppersstraße 18 40549 Düsseldorf Deutschland info@chieftec.eu

Chieftec PowerPlay power supply unit 550 W 20+4 pin ATX PS/2 Black, Red
