Ensure data protection for performance-hungry applications in high-end servers utilizing PCIe 4.0 and a mix of internal SAS, SATA or NVMe storage devicesThe MegaRAID 9500 series is the industry s first PCIe Gen 4.0 RAID adapter family, offering PCIe Gen 4.0 host and storage interfaces. The MegaRAID 9560-8i adapter, based on the SAS3908 high-port count PCIe 4.0 x8 RAID-on-Chip (RoC), delivers twice the performance of previous generations. The 9560-8i is compatible with existing PCIe SFF-8639 Module (U.2) backplanes, allowing users to boost performance for today s ever increasing bandwidth environments. Coupled with two industry initiatives expanding the deployment of Tri-Mode SerDes technology, which enables the operation of NVMe, SAS or SATA devices in a single drive bay, the 9560-8i is instrumental in getting the most performance and flexibility out of U.3 backplanes:- SFF-TA-10001 Specification (U.3), which defines a common bay type for SAS, SATA and NVMe- Universal Backplane Management (UBM), which defines a common backplane control and management frameworkWith Tri-Mode SerDes technology, the adapter negotiates between speeds and protocols to seamlessly work with any of the three types of storage devices. Tri-Mode support provides a non-disruptive way to evolve existing data center infrastructure.
| Ports & interfaces | |
| Supported storage drive interfaces: | SAS, Serial ATA III |
| Host interface: | PCI Express x8 |
| PCI Express slots version: | 4.0 |
| Performance | |
| RAID levels: | 0, 1, 5, 10, 50, 60, JBOD |
| RAID Level Migration: |  |
| Data transfer rate: | 12 Gbit/s |
| SSD support: | |
| Internal memory type: | DDR3 |
| S.M.A.R.T. support: | |
| Number of devices supported: | 240 |
| Online Capacity Expansion: | |
| Certification: | EN55022, EN55024, EN60950, EN 61000-3-2, EN 61000-3-3; FCC Class A, Class B; UL1950; UL; CSA C22.2; VCCI; RRL for MIC; BSMI; C-tick |
| System requirements | |
| Windows operating systems supported: | |
| Linux operating systems supported: | |
| Operational conditions | |
| Operating temperature (T-T): | 10 - 55 °C |
| Storage temperature (T-T): | -45 - 105 °C |
| Operating relative humidity (H-H): | 20 - 80% |
| Storage relative humidity (H-H): | 5 - 95% |
| Logistics data | |
| Harmonized System (HS) code: | 84733080 |
