Axis P3285-LVE Kit License Plate Verifier

Why Choose Axis P3285-LVE Kit License Plate Verifier>

Product no.: 03631-001
Axis P3285-LVE Kit License Plate Verifier
Axis P3285-LVE Kit License Plate Verifier
Axis P3285-LVE Kit License Plate Verifier
Axis P3285-LVE Kit License Plate Verifier
Axis P3285-LVE Kit License Plate Verifier
Axis P3285-LVE Kit License Plate Verifier
Axis P3285-LVE Kit License Plate Verifier
Axis P3285-LVE Kit License Plate Verifier
Axis P3285-LVE Kit License Plate Verifier
Axis P3285-LVE Kit License Plate Verifier
Axis P3285-LVE Kit License Plate Verifier
Axis P3285-LVE Kit License Plate Verifier
Axis P3285-LVE Kit License Plate Verifier
Axis P3285-LVE Kit License Plate Verifier
Axis P3285-LVE Kit License Plate Verifier
Axis P3285-LVE Kit License Plate Verifier
Shipping time:on Stock, 2-4 days
Stock: Only 8 pcs on stock
Today's shipping of your order still possible:4 Std 6 min
1.595,36 €
21 % VAT incl. excl. Shipping costs
Quantity
Add to cart
  • Details
Products description

LPR dome camera kit for slow speed traffic
Built for slow speed traffic, this vandal-resistant, all-in-one LPR kit offers an easy, cost-effective way to capture license plates and other vehicle details. Purpose-tuned and easy to deploy, it supports added access control capabilities.

Enable easy, edge-based license plate recognition
AXIS P3285-LVE Kit License Plate Verifier offers a 2 MP purpose-tuned Axis dome camera with AXIS License Plate Verifier preinstalled. Easy to deploy and intuitive to use, it s out-of-the-box ready for close-up license plate capture. With a powerful deep learning processing unit (DLPU), it can recognize vehicle details under optimal conditions, including type, color, make, and model - no external servers required. It's easy to manage allow and block lists directly on the camera to determine if a vehicle can enter a controlled area. Advanced search and filtering make it quick to locate specific vehicles.

Scale with access control capabilities
This LPR kit supports vehicle access control, from simple entry and exit to advanced access control. Built-in I/O can trigger actions such as opening gates based on LPR events. Axis network door controllers enable scalable access control with support for advanced credential management and fallback card readers. This IP-based device can trigger automated visual and audio alerts on other devices, such as activating a strobe speaker. Built on open APIs, it seamlessly integrates with your existing VMS and third-party platforms. When integrated with AXIS Camera Station Secure Entry and AXIS Camera Station, you can manage vehicle access and building security events through a single interface.

Capture sharp images 24/7 in all environments
With 2 MP resolution at 25/30 fps, AXIS P3285-LVE Kit delivers the image clarity and frame rate needed for accurate and highly reliable license plate recognition. Thanks to Lightfinder 2.0 and OptimizedIR, it captures sharp, high-contrast images and ensures readability 24/7 - even in challenging light like strong headlights and pitch darkness. This vandal-resistant, IK10-rated camera is safe to use even when installed at lower, accessible heights. It operates from -40 to 50 °C (-40 to 122 °F) and shock detection notifies you if there s any attempts to interfere with the camera. Furthermore, Axis Edge Vault safeguards the device and protects sensitive information from unauthorized access.

Performance
Type:IP security camera
Placement supported:Indoor & outdoor
Connectivity technology:Wired
PTZ control:Yes
PTZ modes:Digital PTZ
Auto-tracking:Yes
Tour recording:Yes
Wide Dynamic Range (WDR):Yes
Day/night mode:Yes
Certification:UL/cUL, CE, KC, EAC, VCCI, RCM, ICES, UKCA, FCC
Design
Mounting type:Ceiling/wall
Product colour:Black, White
Form factor:Dome
LED indicators:Yes
Housing material:Plastic, Polycarbonate (PC)
Protection features:Impact resistant, Vandal proof
International Protection (IP) code:IP66
IK code:IK10
Weatherproof:Yes
Camera
Camera pan control:Yes
Camera tilt control:Yes
Minimum illumination:0.02 lx
Angle of rotation:190°
Lens viewing angle, horizontal:100°
Lens viewing angle, vertical:52°
Tilt angle range:-45 - 80°
Pan range:-190 - 190°
Camera pixel size:2.9 µm
Camera shutter speed:1/37000 - 2 s
Image sensor
Sensor type:CMOS
Number of sensors:1
Optical sensor size:25.4 / 2.8 mm (1 / 2.8")
Lens system
Number of lenses:1
Zoom capability:Yes
Lens diameter:1 cm
Focal length range:3.4 - 9.8 mm
Auto focus:Yes
Maximum aperture number:1.76
Minimum aperture number:1.7
Detect distance (wide):48 m
Detect distance (tele):135 m
Observe distance (wide):19 m
Observe distance (tele):54 m
Recognize distance (wide):9.6 m
Recognize distance (tele):27 m
Identify distance (wide):4.8 m
Identify distance (tele):14 m
Closest focusing distance:1 m
Night vision
Night vision:Yes
Night vision distance:40 m
LED type:IR
Infra-red wavelength:850 nm
Video
Maximum resolution:1920 x 1080 pixels
Total megapixels:2 MP
Video formats supported:AV1, AVC, H.264, H.265, HEVC, M-JPEG, MPEG4
Supported graphics resolutions:1280 x 800 (WXGA), 1440 x 1080, 1920 x 1080 (HD 1080)
Frame rate:60 fps
Video streaming:Yes
Noise reduction technology:2D noise reduction, 3D noise reduction
Image quality adjustment:Brightness, Contrast, Saturation, Sharpness
Flip & mirror:Yes
Text caption overlay:Yes
Bit rate control:Variable Bit Rate (VBR)
Audio
Signal-to-Noise Ratio (SNR):55 dB
Audio detection:Yes
Network
Ethernet LAN:Yes
Ethernet interface type:Fast Ethernet
Networking standards:IEEE 802.1AE, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at
Supported network protocols:IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS , HTTP/ 2, TLS , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP, SNMP v1/v2c/v3 (MIBII), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP/ RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/ v6, ARP, SSH, LLDP, CDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf)
Streaming method:Multicast
Storage
Card reader integrated:Yes
Compatible memory cards:MicroSD (TransFlash), MicroSDHC, MicroSDXC
Flash memory:8000 MB
RAM capacity:2000 MB
Ports & interfaces
Ethernet LAN (RJ-45) ports:1
Terminal block port:Yes
Security
Video motion detection:Yes
Active tampering alarm:Yes
Security algorithms:256-bit AES-XTS, EAP-TLS, HTTPS, MSCHAPv2, PEAP
Alert notification type:E-mail
Privacy protection:Yes
Pixel counter:Yes
Human and vehicle targets classification:Yes
Management features
Behavior analysis:Line crossing detection
Power
Power source type:PoE
Power consumption (typical):3.4 W
Power consumption (max):10 W
Operational conditions
Operating temperature (T-T):-40 - 50 °C
Storage temperature (T-T):-40 - 65 °C
Operating relative humidity (H-H):10 - 100%
Storage relative humidity (H-H):5 - 95%
Weight & dimensions
Width:183 mm
Depth:156 mm
Height:149 mm
Weight:850 g
Packaging content
Number of cameras:1
Sun shield included:Yes
Manual:Yes
Other features
Doesn't contain:CFR, PVC, PVC/BFR
