- Details
Broadcast-grade, uncompromised 4K video over IP performance with nearly zero latency.
OmniStream delivers the highest quality 4K imagery using SMPTE VC-2 visually lossless compression (SMPTE 2042) with extremely low latency. VC-2 is optimized for video distribution over readily available Gigabit Ethernet infrastructure.
Fully scalable from rooms to campuses and enterprises. Imagine the possibilities.
AV over IP technology lets you realize opportunities for interconnecting AV throughout a facility, building, or across an entire corporate or university campus. Standard IP network hardware replaces the need for fixed matrix switching systems that are difficult to scale.
Built-in security and network error resilience.
OmniStream features selectable AES128 encryption for securing sensitive or protected AV content in government, healthcare, and other environments. OmniStream is also the only AV over IP platform in the industry with SMPTE 2022 forward error correction for ensuring robust performance over large network installations.
| Video | |
| Maximum video resolution: | 4096 x 2160 pixels |
| Performance | |
| PTZ control: | No |
| Bitrate at maximum video resolution: | 900 Mbit/s |
| Design | |
| Product colour: | Black |
| LED indicators: | Yes |
| Certification: | CE, FCC, cULus, RoHS, CCC, RCM |
| Security | |
| Security algorithms: | 128-bit AES |
| Ports & interfaces | |
| I/O terminal ports: | 0 |
| HDMI input ports quantity: | 1 |
| Ethernet LAN (RJ-45) ports: | 1 |
| Power | |
| Power consumption (typical): | 13 W |
| Weight & dimensions | |
| Width: | 208 mm |
| Depth: | 112 mm |
| Height: | 34 mm |
| Operational conditions | |
| Operating temperature (T-T): | 0 - 50 °C |
| Storage temperature (T-T): | -20 - 60 °C |
| Operating relative humidity (H-H): | 20 - 90% |
