Products description
| Ports & interfaces | |
| Number of computers controlled: | 128 |
| Keyboard port type: | USB, PS/2 |
| Mouse port type: | USB, PS/2 |
| Video port type: | VGA |
| Console ports: | VGA (D-Sub) |
| VGA (D-Sub) ports quantity: | 8 |
| Network | |
| Ethernet LAN: | Yes |
| Ethernet LAN (RJ-45) ports: | 1 |
| Cabling technology: | 10/100/1000Base-T(X) |
| Performance | |
| HD type: | SXGA |
| Maximum resolution: | 1280 x 1024 pixels |
| Video bandwidth: | 75 Hz |
| Scan interval: | 1,255 s |
| DDC2B support: | Yes |
| Hot-Plug support: | Yes |
| Daisy chain: | Yes |
| Firmware upgradeable: | Yes |
| Design | |
| Rack mounting: | Yes |
| Product colour: | Black |
| Rack capacity: | 1U |
| Housing material: | Metal, Plastic |
| LED indicators: | Yes |
| Push button: | Yes |
| Hot keys: | Yes |
| Keyboard language: | Swiss |
| Display | |
| Built-in display: | Yes |
| Display: | LCD |
| Display diagonal: | 43.2 cm (17") |
| On Screen Display (OSD): | Yes |
| Power | |
| Power source: | AC |
| Input voltage: | 100 - 240 V |
| AC input frequency: | 50 - 60 Hz |
| Input current: | 1 A |
| Power consumption (typical): | 27.7 W |
| System requirements | |
| Windows operating systems supported: | Yes |
| Linux operating systems supported: | Yes |
| Mac operating systems supported: | Yes |
| Sustainability | |
| Compliance certificates: | RoHS |
| Operational conditions | |
| Operating temperature (T-T): | 0 - 50 °C |
| Storage temperature (T-T): | -20 - 60 °C |
| Operating relative humidity (H-H): | 0 - 80% |
| Weight & dimensions | |
| Width: | 480 mm |
| Depth: | 642.7 mm |
| Height: | 44 mm |
| Weight: | 13.5 kg |
| Packaging content | |
| Cables included: | AC, KVM |
| Quick installation guide: | Yes |
| Manual: | Yes |
| Rack mount kit: | Yes |
