Products description
Rack-Mountable
Includes horizontal, vertical, and toolless-mount varieties. Puts power where it is needed most - in the racks near the equipment.
Single input power source
Supply power from one branch whip to multiple pieces of equipment, conveniently powering rack-mount equipment. Saves time and money during installation by using one branch whip and standard connections.
Wide range of input and output connections
Product family includes a variety of input and output connections to distribute 120V, 208V, or 230V power to multiple outlets. Having a variety of inputs and outputs allow users to adapt to varying power requirements. APC offers units that bring up to 14.4kW using a single branch whip.
| Design | |
| Rack capacity: | 0U |
| Product colour: | Beige |
| Ports & interfaces | |
| Input connection type: | NEMA 5-15P |
| Output connections: | 14 x NEMA 5-15R |
| Features | |
| Cable length: | 3.6 m |
| Certification: | cUL/CSA/ETI/UL 1363 |
| Power | |
| Nominal input voltage: | 120 V |
| AC input frequency: | 50 - 60 Hz |
| Nominal output voltage: | 120 V |
| Output voltage: | 120 V |
| Load capacity: | 1800 VA |
| Maximum total current draw per phase: | 15 A |
| Weight & dimensions | |
| Dimensions (WxDxH): | 44 x 44 x 610 mm |
| Weight: | 2.18 kg |
| Packaging data | |
| Package dimensions (WxDxH): | 178 x 152 x 648 mm |
| Package weight: | 2.91 kg |
| Operational conditions | |
| Operating temperature (T-T): | 0 - 45 °C |
| Storage temperature (T-T): | -25 - 65 °C |
| Operating relative humidity (H-H): | 0 - 95% |
| Storage relative humidity (H-H): | 0 - 95% |
| Weight (imperial): | 2.18 kg (4.8 lbs) |
