ATEN AT-VS1804T
Product no.: VS1804T
The VS1804T HDMI Over Cat 5 Splitter is a splitter designed to connect one source to 4 displays over a long distance. Incorporating suggested compatible receivers *, the VS1804T HDMI Over Cat 5 Splitter can be a complete solution ideal for any professional A/V installation that requires multimedia content to be delivered to multiple destinations located up to 60 m away from the source.
* Compatible Receiver Units:
VB802 HDMI Over Cat 5 Repeater cadcadable up to five levels
VE800AR HDMI Receiver
VS1804T combined with VB802 and VE800AR units can transmit signals up to 300 m
The VS1804Tsolution is perfect for a wide range of applications:
In-store or tradeshow digital signage
Broadcasting information in public (news, airline or train arrival/departure information)
Sporting events
Theater and lecture rooms
Company training facilities
| Ports & interfaces | |
| Video ports quantity: | 4 |
| Video port type: | HDMI |
| Video out: | HDMI |
| Serial ports quantity: | 1 |
| DC-in jack: |  |
| Features | |
| Maximum resolution: | 1920 x 1080 pixels |
| Product colour: | Black |
| Full HD: | |
| 3D: | |
| Maximum operating distance: | 60 m |
| HD-Ready: | |
| HDCP: | |
| Power LED: | |
| Supported video modes: | 1080i, 1080p, 480p, 720p |
| Certification: | RoHS |
| Network | |
| Ethernet LAN: | |
| Cable types supported: | Cat5, Cat5e |
| Power | |
| AC input voltage: | 100-240 V |
| AC input frequency: | 50 - 60 Hz |
| Power consumption (typical): | 8 W |
| Weight & dimensions | |
| Dimensions (WxDxH): | 432.4 x 154.1 x 44 mm |
| Weight: | 2.1 kg |
| Packaging content | |
| Manual: | |
| User guide: | |
| Operational conditions | |
| Operating temperature (T-T): | 0 - 50 °C |
| Storage temperature (T-T): | -20 - 60 °C |
| Operating relative humidity (H-H): | 0 - 80% |
| Logistics data | |
| Harmonized System (HS) code: | 85176990 |
Price:
279,00 €
19 % VAT incl. excl. Shipping costs
