Bintec-elmeg W2022ac 1267 Mbit/s White Power over Ethernet (PoE)
Product no.: 5510000422
802.11ac access point with MU-MIMO technology for the high-performance support of mobile devices.The bintec W2022ac is an access point based on the latest 802.11ac standard and supports MU-MIMO (Multiple User MIMO). The MU-MIMO technology allows mobile devices (such as smartphones) that have only one antenna to use all the transmission streams of an access point. Compared to 802.11ac first-generation access points, which support only single-user MIMO (SU-MIMO), twice as many mobile devices can connect to the bintec W2022ac without sacrificing performance. This doubles the overall performance.Together with the WLAN controller integrated in be.IP, commissioning becomes child's play. In larger installations, you have the choice between a local installed bintec WLAN controller solution and the bintec Cloud NetManager. In addition, the bintec W2022ac is already prepared for the new bintec be.SDx solution.The new ceiling mount is available as an accessory and allows mounting on suspended system ceilings without drilling and dowels or direct mounting on wood or concrete ceilings. For mounting on the wall, the optional ceiling mount is not necessary.Five-year warranty on the hardware of the bintec W2022ac.
| Features | |
| 2.4 GHz: |  |
| 5 GHz: | |
| Maximum data transfer rate: | 1267 Mbit/s |
| Maximum data transfer rate (2.4 GHz): | 400 Mbit/s |
| Maximum data transfer rate (5 GHz): | 867 Mbit/s |
| Ethernet LAN data rates: | 10,100,1000 Mbit/s |
| Networking standards: | IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az |
| Auto MDI/MDI-X: | |
| MIMO: | |
| MIMO type: | Multi User MIMO |
| Modulation: | 256-QAM, DSSS, OFDM |
| VLAN support: | |
| Security | |
| Security algorithms: | AES, EAP-MD5, EAP-PEAP, EAP-TLS, EAP-TTLS, WPA, WPA2 |
| MAC address filtering: | |
| Service Set Identifier (SSID) features: | SSID broadcast on/off |
| Number of SSID supported: | 8 |
| Wireless Intrusion Detection System (WIDS): | |
| Access Control List (ACL): | |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports: | 2 |
| Power | |
| Power over Ethernet (PoE): | |
| AC input voltage: | 230 V |
| Output voltage: | 12 V |
| Output current: | 1 A |
| Power consumption (max): | 8.95 W |
| Design | |
| Placement: | Ceiling, Wall |
| Product colour: | White |
| LED indicators: | |
| Internal: |  |
| Weight & dimensions | |
| Width: | 190 mm |
| Depth: | 190 mm |
| Height: | 38 mm |
| Weight: | 505 g |
| Packaging content | |
| Number of products included: | 1 pc(s) |
| Operational conditions | |
| Operating relative humidity (H-H): | 10 - 95% |
| Operating temperature (T-T): | 0 - 40 °C |
| Storage temperature (T-T): | -10 - 70 °C |
| Storage relative humidity (H-H): | 10 - 95% |
| Logistics data | |
| Harmonized System (HS) code: | 85176990 |
